{Description}
25-400mm LEICA DC VARIO-ELMARIT Lens
1-inch 20.1-megapixel High Sensitivity MOS Sensor
4K Video and 4K PHOTO
High Speed Response Featuring DFD Technology
2,360k-dot High-resolution OLED LVF and Touch-control Rear Monitor
Zoom Compose Assist function

{Specification}
Dimensions (W x H x D) 136.2 x 97.2 x 131.5 mm (5.36 x 3.83 x 5.18 inch)
Weight Approx. 810 g with Battery and SD Memory Card (1.79 lb)
Approx. 758 g without Battery and SD Memory Card (1.67 lb)
Optics Pixels Camera Effective Pixels 20.1 Megapixels
Sensor Sensor Size / Total Pixels / Filter 1-inch High Sensitivity MOS Sensor / 20.9 Total Megapixels / Primary Color Filter
Lens Aperture F2.8 - 4.0 / Multistage Iris Diaphragm (F2.8 - 11 (W), F4.0 - 11 (T))
Optical Zoom 16x
Focal Length f = 9.1 - 146mm
(27 - 432mm in 35mm equiv. in 4:3)
(25 - 400mm in 35mm equiv. in 3:2)
(26 - 416mm in 35mm equiv. in 16:9)
(32 - 512mm in 35mm equiv. in 1:1)
(26 - 416mm in 35mm equiv. in 16:9 video recording / O.I.S. Off / Level Shot function Off)
(28 - 448mm in 35mm equiv. in 16:9 video recording / O.I.S. On / Level Shot function Off)
(31 - 496mm in 35mm equiv. in 16:9 video recording / O.I.S. On / Level Shot function On)
(37 - 592mm in 35mm equiv. in 4K video / 4K PHOTO recording)
Extra Optical Zoom (EZ) 22.4x (3:2 / 10M (M)), 32x (3:2 / 5M (S))
Intelligent Zoom 32x
Lens LEICA DC VARIO-ELMARIT
15 elements in 11 groups
(5 aspherical lenses / 8 aspherical surfaces / 4 ED lenses)
Optical Image Stabilizer 5-Axis HYBRID O.I.S. +*
*5-Axis compensation works in video recording except for 4K video or high-speed video recording.
Digital Zoom Max. 4x (When Digital Zoom is used simultaneously with Intelligent Zoom, you can only increase the zoom ratio up to 2x.)
Focus Focusing Area Normal: Wide 30 cm - infinity / Tele 100 cm - infinity
AF Macro / MF / Intelligent Auto / Motion Picture: Wide 3 cm - infinity / Tele 100 cm - infinity
AF Assist Lamp Yes (On / Off)
Focus AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF
AF Macro, Macro Zoom, Quick AF, Continuous AF (during motion picture recording), Touch AF/AE Function, Touch Shutter, Eye Sensor AF, Touch Pad AF, MF Assist, Touch MF Assist, AF+MF, Focus Peaking, One Shot AF (Set the Fn button in custom menu to AF-ON), Low Light AF, Starlight AF
Post Focus Yes
Focus Stacking Yes
AF Metering Face/Eye Detection / Tracking / 49-area / Custom Multi / 1-area / Pinpoint
(Full area touch is available)
Shutter Shutter Speed [Still Image] Still Image:
Approx. 60 - 1/4,000 sec (Mechanical Shutter)
Approx. 1 - 1/16,000 sec (Electronic Shutter)
Bulb (Approx. 120 sec)
Shutter Speed [Motion Picture] Motion Picture:
Approx. 1/25 - 1/16,000 sec
Approx. 1/2 - 1/16,000 sec (Creative Video M Mode / MF Mode)
Recording File File Format Still Image: JPEG (DCF/Exif2.31) / RAW
4K PHOTO: MP4
Motion Picture: AVCHD Progressive, AVCHD (Audio format: Dolby Audio 2ch), MP4 (Audio format:
AAC 2ch)
Recording Modes Recording Mode Intelligent Auto, P, A, S, M, Creative Video, C (Custom), Panorama Shot, Scene Guide, Creative Control
Filter Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome* / Silky Monochrome* / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Soft Focus* / Fantasy / Star Filter* / One Point Color / Sunshine* (22 filters) *For photos only.
Scene Guide Clear Portrait, Silky Skin, Backlit Softness, Clear in Backlight, Relaxing Tone, Sweet Child's Face, Distinct Scenery, Bright Blue Sky, Romantic Sunset Glow, Vivid Sunset Glow, Glistening Water*, Clear Nightscape, Cool Night Sky, Warm Glowing Nightscape, Artistic Nightscape, Glittering Illuminations*, Handheld Night Shot, Clear Night Portrait, Soft Image of a Flower*, Appetizing Food, Cute Dessert, Freeze Animal Motion, Clear Sports Shot, Monochrome *For photos only.
Burst Shooting Mode (Approx.) <Actinic:Variable Name = 'AFS'/> H: 12 frames/sec, M: 7 frames/sec (with Live View), L: 2 frames/sec (with Live View)[AFF/AFC] H: 7 frames/sec (with Live View), M: 7 frames/sec (with Live View), L: 2 frames/sec (with Live View)
4K Photo Mode (*2) 4K Burst: 30 frames/sec, max. 29 min 59 sec
4K Burst (S/S): 30 frames/sec, max. 29 min 59 sec
4K Pre-Burst: 30 frames/sec, approx. 2 sec
Exif Information: Yes (Each JPEG image cropped out of the 4K burst file complies with EXIF.)
Auto Marking Function: Auto / Face Priority / Motion Priority (in 4K Burst mode and 4K Burst (S/S) mode)
Motion Picture Recording (*2) MP4 4K]3840x2160 4K/30p: 100Mbps
<Actinic:Variable Name = '4K'/>3840x2160 4K/25p: 100Mbps
<Actinic:Variable Name = '4K'/>3840x2160 4K/24p: 100Mbps
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/60p: 28Mbps
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/50p: 28Mbps
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/30p: 20Mbps
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/25p: 20Mbps
<Actinic:Variable Name = 'HD'/>1280x720 HD/30p: 10Mbps
<Actinic:Variable Name = 'HD'/>1280x720 HD/25p: 10Mbps
AVCHD FHD]1920x1080 FHD/50p: 28Mbps, 50p recording
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/50i: 17Mbps, 50i recording
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/25p: 24Mbps, 50i recording (sensor output is 25fps)
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/24p: 24Mbps, 24p recording
High Speed Video(*2) MP4 <Actinic:Variable Name = 'FHD'/>1920x1080 FHD/30p (Sensor Output is 120fps)
<Actinic:Variable Name = 'FHD'/>1920x1080 FHD/25p (Sensor Output is 100fps)
Continuous Recordable Time (Motion Pictures) (*2) MP4 4K/30p, 4K/25p: Approx. 120 min
FHD/60p, FHD/50p: Approx. 130 min
AVCHD FHD/50p, FHD/50i: Approx. 130 min
Actual recordable Time (Motion Pictures) (*2) MP4 4K/30p, 4K/25p: Approx. 60 min
FHD/60p, FHD/50p: Approx. 65 min
AVCHD FHD/50p, FHD/50i: Approx. 65 min
Exposure Parameters Exposure Program AE, Aperture Priority AE, Shutter Priority AE, Manual
Exposure Compensation 1/3 EV step, +/-5 EV (+/-3 EV for motion picture / 4K PHOTO)
Light Metering Intelligent Multiple / Center Weighted / Spot
ISO Sensitivity Still Image: Auto / i.ISO / 80* / 100* / 125 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600* *Extended ISO
Motion Picture: Auto / 80* / 100* / 125 / 200 / 400 / 800 / 1600 / 3200 / 6400 *Extended ISO
(Changeable to 1/3 EV step)
Picture Quality Still Picture Recording 4:3 4864x3648 (17.5M) (L) / 3456x2592 (9M) (M) / 2432x1824 (4.5M) (S)
3:2 5472x3648 (20M) (L) / 3888x2592 (10M) (M) / 2736x1824 (5M) (S)
16:9 5472x3080 (17M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)
1:1 3648x3648 (13.5M) (L) / 2592x2592 (6.5M) (M) / 1824x1824 (3.5M) (S)
Image Quality RAW / RAW+Fine / RAW+Standard / Fine / Standard
White Balance AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Color Temperature Setting
(2-axis adjustable)
Photo Style Standard, Vivid, Natural, Monochrome, L. Monochrome, L. Monochrome D, Scenery, Portrait, Custom, Cinelike D, Cinelike V
Picture Adjustment Contrast, Sharpness, Noise Reduction, Saturation*, Color Tone**, Filter Effect**, Grain Effect***Except for Monochrome mode. **For Monochrome mode only.
Bracket AE Bracket 3, 5, 7 images in 1/3, 2/3 or 1 EV step, Max. +/-3 EV
Aperture Bracket 3, 5 or all positions in 1 EV step
Focus Bracket 1 to 999 images, focus steps can be set in 10 levels
White Balance Bracket 3 images in blue/amber axis or in magenta/green axis
Other Digital Red Eye Correction (Red-Eye Removal) Yes (On / Off)
Wi-FI IEEE 802.11b/g/n
2412 MHz - 2462 MHz (1-11 ch)
WPA / WPA2
Infrastructure Mode / WPS
Bluetooth Bluetooth® v4.2 (Bluetooth Low Energy (BLE))
Self Timer 2 sec / 10 sec / 10 sec (3 images)
Playback Display Playback Mode All, Picture Only, Video Only, Slideshow (All / Picture Only / Video Only, duration & effect is selectable), Calendar
Thumbnails / Zoomed Playback 12,30-thumbnails / Yes
Rating / Rotate Image / Protect Yes / Yes / Yes
Show Histogram/ Show Highlights Yes / Yes
Edit Retouch Clear Retouch
Image Composition Light Composition, Sequence Composition
Creating a Motion Picture from Still Pictures Time Lapse Video, Stop Motion Video
RAW Processing Yes
Resize/ Cropping Yes / Yes
Title Edit / Text Stamp Yes / Yes
Video Divide Yes
Direct Print PictBridge compatible
Setup OSD language English, Chinese (Traditional), Chinese (Simplified), Thai, Arabic, Persian, Vietnamese, Hindi
Others Finder Viewfinder 0.39" OLED LVF (Live View Finder) (2,360k dots), Field of View: Approx. 100%
Magnification: Approx. 0.74x (35 mm camera), Eye point: Approx. 20mm from eyepiece lens
Monitor LCD Monitor 3.0" (7.5cm) Free-angle TFT Screen LCD Display (1240k dots) Static Touch Control
Field of View: Approx. 100%
Flash Built- in- Flash Auto*, Auto/Red-eye Reduction*, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off *For iA, iA+ mode only.
Flash Synchro: 1st / 2nd Slow Sync.
Synchronization for flash dimming and exposure compensation 0.3 - 13.5m (Wide / ISO Auto), 1.0 - 9.5m (Tele / ISO Auto)
Media Recording Media SD Memory Card, SDHC Memory Card, SDXC Memory Card
(Compatible with UHS-I UHS Speed Class 3 standard SDHC / SDXC Memory Cards)
Audio Microphone / Speaker Stereo / Mono
Interface Interface microHDMI typeD (*3), USB2.0 Micro-B
Remote Input f2.5mm
External Microphone Input f3.5mm
Power Power Li-ion Battery Pack (7.2V, 1200mAh, 8.7 Wh) (Included)
USB power charging
Battery life (Approx.) Approx. 440 images (rear monitor), 290 images (LVF), 430 images (LVF eco30fps setting) (
